8KW 10KVA 3 Phase CHP Cogeneration Power

Residential CHP
December 25, 2025
Category Connection: Residential CHP
Chat Now Contact Us
Tags:
#residential cogeneration units #domestic cogeneration systems #home combined heat and power
Brief: Watch as we walk through the full process, from initial setup to real-world testing of the 3 Phase Residential CHP. This video demonstrates how the 8KW 10KVA cogeneration unit recovers heat from four different sources and showcases its operation with a water-cooled alternator in a grid-on configuration.
Related Product Features:
  • Generates 8kW of continuous electrical power and 20.4kW of thermal output with an overall efficiency of 90.9%.
  • Recovers waste heat from four sources: engine jacket water, alternator cooling water, exhaust, and exhaust manifold.
  • Features a robust SP9EW engine with 4 cylinders, 4-stroke, 16 valves, and water-cooled operation at 1500 RPM.
  • Equipped with a water-cooled asynchronous alternator offering IP65 protection and class H insulation.
  • Includes premium components like SWEP heat exchangers, Woodward speed governor, and ABB soft start and switch.
  • Operates on natural gas with a consumption of 0.396 m³/kW.h and a gas inlet pressure range of 1-10 kPa.
  • Designed for 3-phase, 400/230V, 50Hz electrical systems with a compact, soundproof enclosure.
  • Offers optional features such as lambda control and a catalyst converter upon request.
FAQs:
  • What is the total efficiency of this 8KW CHP unit?
    The 3 Phase Residential CHP achieves an impressive overall efficiency of 90.9%, combining 25.6% electrical efficiency and 65.3% thermal efficiency from heat recovery.
  • From which sources does the CHP recover heat?
    This cogeneration unit recovers waste heat from four key sources: the engine jacket water, the alternator cooling water, the exhaust system, and the exhaust manifold, maximizing energy utilization.
  • What are the key specifications of the engine used in this CHP?
    The CHP is powered by a SP9EW engine, which is a 4-cylinder, 4-stroke, 16-valve, water-cooled engine with a displacement of 1.5L, operating at 1500 RPM with an 11:1 compression ratio.
  • Is this unit suitable for grid connection?
    Yes, this 8KW 10KVA CHP is designed for grid-on cogeneration, meaning it can synchronize with and supply power to the electrical grid while also providing thermal energy.
