3 Phase 250KW Industrial CHP , Industrial Cogeneration With Heat Recovery System
| Place of Origin | Chengdu,China |
|---|---|
| Brand Name | SevenPower |
| Certification | CE |
| Model Number | SP250N |
| Minimum Order Quantity | 1 Set |
| Price | Negotiable |
| Delivery Time | 30days |
| Payment Terms | L/C, T/T |
Product Details
| Fuel | Natural Gas | Frequency | 50Hz, 60Hz Is Available On Request |
|---|---|---|---|
| Electrical Output | 200kw | Color | White Or Black, Other Colors Please Consult With The Sales |
| Emissions | Below 500mg/Nm3 | Sounproof Canopy | With Or Without |
| High Light | industrial heat and power,industrial cogeneration |
||
Product Description
250KW 3 Phase Natural Gas Generator Set With CHP Energy Saving Unit Backup Power
Why SevenPower?
- Environmentally friendly design
- Long time research and development and testing for high reliability
- Comprehensive heat insulation to minimize heat losses
- Water-to-water heat exchanger/SWEP, self-developed exhaust heat exchanger which is made of full stainless steel #316 instead of universal carbon steel which get rusty easily.
- CHP inner pipeline is made of full stainless steel.
- Maximum lower the noise level
- Maintenance friendly thanks to easy access
- Long service intervals
- Suitable for mains parallelling
- CE approved
After-sale Service
- Installation and maintenance guide
- Free debugging
- Training the operator
- Supply the spare parts during the whole service life.
- Overseas service
Main Specifications
| Model | SP250N | |
| fuel | — | Natural Gas |
| marks | — | Synchro CHP |
| electrical output(KWe) | kVA/kWe | Continuous Power |
| 313/250 | ||
| thermal output(KWe) | kWt | 330 |
| electrical efficiency | % | 36.2% |
| thermal efficiency | % | 47.8% |
| overall efficiency | % | 84% |
| frequency | Hz | 50 |
| voltage | V | 400/230 |
| gas inlet pressure | kPa | 3-5 |
| dimension (soundproof type) | mm*mm*mm | 3500*1800*2000 |
| net weight | kg | 4000 |
| NG consumption | m3/kW.h | 0.28 |
| db(A)@7m | — | 59 |
| Certificate | — | CE |
| water-water heat exchanger | — | SWEP |
| water-exhaust heat exchanger | — | designed by our own factory/made of full stainless steel |
| ignition system | — | Altronic |
| speed governor | — | Woodward |
| mixer | — | Venturi type |
| gas filter | — | Madas |
| zero regulator | — | Kromschroeder |
| solenoid valve | — | Kromschroeder |
| gas pressure gauge | — | Dungs |
| Lambda auto control | — | Available on request with extral cost |
| catalyst converter | — | Available on request with extral cost |
| MCB | — | ABB |
| GCB | — | ABB |
| Controller | ComAp | |
| Engine model | — | MAN MT13 |
| Engine type | — | 6 cylinders,4stroke,water-coolled |
| RPM | — | 1500 |
| Compression Ratio | — | 11.5 |
| Displacement | — | 12.419L |
| Oil capacity | — | 40L |
| Charging voltage | — | 24V(DC) |
| Charging current | — | 5A(DC) |
| Starting system | — | Electic-start |
| Alternator model | — | Meccalte |
| phase | — | 3 phase 4 wires |
| insulation system | — | class H |
| protection | — | IP23 |
| Cooling Type | — | air cooled |
SevenPower Natural Gas CHP 250KW On Site Picture
For more information about the 250KW CHP, please consult with your sales representative.Thanks.
