150KVA Natural Gas CHP , Combined Heat Power System RPM1800 Low Speed Low Noise

60Hz 3 Phase 220V 120KW 150KVA Natural Gas CHP RPM1800 Low Speed Low Noise


Pre- sale Service

- Provide specifications consultation, customized design proposal.

- Welcome to visit our factory for inspection.

- Check and see the products running

- Train operators

After – sale Service

- Installation guide and maintenance manual

- Guide user to install the machine and debug the machine for free.

- Training the operators for safe operation

- Supply the spare parts during the whole service life.

- Overseas maintenance service

- Collecting feedbacks from end user ,avoid potential problem and solve problems in time.


Main Specifications

Model SP120N

fuel — Natural Gas

electrical output  Continuous Power 150 / 120 kVA / kWe

thermal output(KWe) kWt 172

electrical efficiency   33.8%

thermal efficiency   48.5%

overall efficiency   82.3%

frequency  60Hz

gas inlet pressure kPa 3-5

dimension (soundproof type)  2600*1550*1650mm*mm*mm

net weight kg 2700

NG consumption m3 / kW.h 0.3

db(A) @ 7m — 58

Certificate — CE

water-water heat exchanger — SWEP

water-exhaust heat exchanger — designed by our own factory/made of full stainless steel

ignition system — Impco

speed governor — Woodward

mixer — Venturi type

gas filter — Madas

zero regulator — Kromschroeder

solenoid valve — Kromschroeder

gas pressure gauge — Dungs

Lambda auto control — Available on request with extral cost

catalyst converter — Available on request with extral cost

MCB — ABB

GCB — ABB

Controller ComAp

Engine model — SP-6CTA

Engine type — 6 cylinders,4stroke,water-coolled

RPM — 1500

Compression Ratio — 10.5

Displacement — 8.3L

Oil capacity — 19L

Charging voltage — 24V(DC)

Charging current — 5A(DC)

Starting system — Electic-start

Alternator model — Meccalte

phase — 3 phase 4 wires

insulation system — class H

protection — IP23

Cooling Type — air cooled


Optional at

• Leroy Somer or Faraday Or Stamford alternator
• ComAp or Deepsea or SmartGen controller
• Off-grid or Mains parallel.
• CHPs in parallel
• Emissions(NOx and CO)


SevenPower 100KW Natural Gas CHP On Site Picture(Europe)




For more information about each CHP, please consult with your sales representative.Thanks.
