SevenPower standard CHP units all adopt closed loop circulation, liquid - liquid heat exchange cooling method.The closed loop cooling system consists of the following parts:

- expansion water pot

- water pump

- engine internal water channel

- thermostat

- liquid - liquid heat exchanger

- corrugated metal pipes

- water cooled exhaust pipe

Characters

- CE approved.

- Powered by converted C UMMINS engine/converted piston, piston rings, cam shaft, cylinder head.

- Alternator is optional at Meccalte / Leroy Somer / Protection level IP23 / Insulation Level Class H

- Controller ComAp(Available at different control demands).

- Emission is available on request.

Main Specifications

	Model	SP60N
	Model	SP60N
fuel	—	Natural Gas
marks	—	Synchro CHP
electrical output(KWe)	kVA/kWe	Continuous Power
electrical output(KWe)	kVA/kWe	75/60
thermal output(KWt)	kWt	108
electrical efficiency	%	29.8%
thermal efficiency	%	53.7%
overall efficiency	%	83.5%
frequency	Hz	50
voltage	V	380/220
gas inlet pressure	kPa	3-5
dimension (soundproof type)	mmmmmm	250014001600
net weight	kgs	2000
NG consumption	m3/kW.h	0.34
standard type-db(A)@7m	—	58
Certificate	—	CE
water-water heat exchanger	—	SWEP
water-exhaust heat exchanger	—	designed by our own factory/made of full stainless steel
ignition system	—	Impco
speed governor	—	Woodward
mixer	—	Venturi type
gas filter	—	Madas
zero regulator	—	Kromschroeder
solenoid valve	—	Kromschroeder
gas pressure gauge	—	Dungs
Lambda auto control	—	Yes
catalyst converter	—	Optional
MCB	—	ABB
GCB	—	ABB

Engine	Engine model	SP-6BTA
	Engine type	6 cylinders,4stroke,water-coolled
	RPM	1500
	Compression Ratio	10.5
	Displacement	5.9L
	Oil capacity	17L
	Charging voltage	24V(DC)
	Charging current	5A(DC)
	Starting system	Electic-start
Alternator	Insulation	Class H
	Protection	IP23

For more information about the 60kw CHP, please consult with your sales representative.Thanks.
