3 Phase Natural Gas Combined Heat And Power Machine 60Hz 40KW CE Approved

Brand Name:	SevenPower
Model Number:	SP40N
MOQ:	1 Set
Price:	Negotiable
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Chengdu,China

Certification:

Frequency:

60Hz, 50Hz Is Available On Request

Electrical Output:

40KW

Color:

Black, Other Colors Is Available On Request

Soundproof Canopy:

With Or Without

Fuel:

Natural Gas

Emissions:

Available On Request

Power Factor:

0.8

Voltage:

440/254V, Other Voltage Is Available On Request

Highlight:

natural gas combined heat and power

natural gas cogen

Product Description

60Hz 3Phase 40KW 440V / 2540V Natural Gas Combined Heat And Power Machine CE Approved

Control Features

- The monitor and display on the voltage, current, frequency, active power, apparent power, power factor of the generated electricity / grid electricity.
- The monitor and display on the CHP water temperature, oil pressure, rotational speed, battery voltage, running hours, accumulative total power and number of starts.
- Protection alarm and fault automatic storage on high water temperature, low oil pressure, double speeding, over current, over voltage, over frequency and phase failure etc.

Scope Of Supply

a) Gas engine with all accessories
b) Alternator
c) Base or Soundproof canopy
d) Water-water heat exchanger
e) Exhaust heat exchanger
f) Gas train
g) Air filter
h) Control panel
i) Circuit breaker
j) Shock absorber
k) High-efficient silencer

Main Specifications

	Model	SP40N
	Model	SP40N
fuel	—	Natural Gas
marks	—	Synchro CHP
electrical output(KWe)	kVA/kWe	Continuous Power
electrical output(KWe)	kVA/kWe	50/40
thermal output(KWt)	kWt	65.2
electrical efficiency	%	32.7%
thermal efficiency	%	53.3%
overall efficiency	%	86%
frequency	Hz	60
voltage	V	440/254
gas inlet pressure	kPa	3-5
dimension (soundproof type)	mmmmmm	220012001500
net weight	kgs	1100
NG consumption	m³/kW.h	0.31
standard type-db(A)@7m	—	58
Certificate	—	CE
water-water heat exchanger	—	SWEP
water-exhaust heat exchanger	—	designed by our own factory/made of full stainless steel
ignition system	—	Impco
speed governor	—	Woodward
mixer	—	Venturi type
gas filter	—	Madas
zero regulator	—	Kromschroeder
solenoid valve	—	Kromschroeder
gas pressure gauge	—	Dungs
Lambda auto control	—	Available on request with extral cost
catalyst converter	—	Available on request with extral cost
MCB	—	ABB
GCB	—	ABB
Controller		ComAp
Engine model	—	SP-4BTA
Engine type	—	4 cylinders,4stroke,water-coolled
RPM	—	1500
Compression Ratio	—	10.5
Displacement	—	3.9L
Oil capacity	—	9.5L
Charging voltage	—	24V(DC)
Charging current	—	5A(DC)
Starting system	—	Electic-start
Alternator model	—	Meccalte
phase	—	3 phase 4 wires
insulation system	—	class H
protection	—	IP23
Cooling Type	—	air cooled

Scope Of Application
3 Phase Natural Gas Combined Heat And Power Machine 60Hz 40KW CE Approved 0

For more information about the 40kw CHP, please consult with your sales representative.Thanks.
