Micro Generator Diesel CHP Super Silent Low Emissions 20KW 25KVA

Brand Name:	SevenPower
Model Number:	SP20
MOQ:	1 Set
Price:	Negotiable
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Chengdu,China

Certification:

Fuel:

Diesel

Frequency:

50Hz, 60Hz Is Available On Request

Engine Cooling:

Water Cooled

Cylinders:

Speed:

Exhaust Heat Exchanger:

Made Of Stainless Steel

Water-water Heat Exchanger:

Highlight:

Micro Generator Diesel CHP

20KW Diesel CHP

25KVA CHP Diesel Generator

Product Description

Diesel CHP 20KW 25KVA Micro Generator CHP Super Silent Low Emissions

Due to the energy crisis, there's big market for Diesel CHP.Diesel application is more widely than other gases in the global , and the supply is adequate, it’s easy for transportation and preservation, convenient energy supply to remote areas, to provide more stable fuel source for Diesel CHP

Our factory SevenPower have been selling gas CHPs in Europe for about 10years, now we have distributors and showroom in Germany.

Why SevenPower CHPs?

- Water cooled engine, stable performance
- Exhaust heat exchanger made of full stainless steel
- CE approved.
- Environmentally friendly design.
- Long time R&D and testing ensure high reliability.
- Maximum lower the noise level.
- Insulation reduce the heat loss
- Maintenance friendly thanks to easy access.

Diesel Cogenerator
Model			SP20
CHP	Rated output	KW/KVA	20/25
	Max. output	KW/KVA	22/28
	Heat output	KWt	35
	Electrical efficiency	%	31.5%
	Thermal efficiency	%	55.15%
	Overall efficiency	%	86.65%
	Rated frequency	Hz	50
	Rated Voltage	V	230/400
	Rated current	A	36
	Rated rotation speed	rpm	1500
	Phase NO.		Three phase "Y" type connection
	Power factor		0.8(lag)
	Panel Type		Digital Panel
	Auto floating charting		YES
	Overall dimension: L×W×H	mm	18009601170(without removable doors width 780mm only)
	Net weight	Kgs	700
	Noise level @1meter	dB(A)	60dB(A)@full load
	Structure type		Ultra silent
Engine	Engine Model		4JB1 (ISUZU/made in china)
	Engine Type		water cooled, in line, internal combustion
	Cylinder NO.-bore×stroke	mm	4Cylinders-93×102
	Displacement	ml	2771
	Rated power	kW	24/1500
	Compression ratio		18.2:1
	Rated rotation speed	r/min	1500
	Cooling system		Water cooled
	Lubrication system		Pressure splash
	Starting system		Electric starter
	Fuel type		Diesel
	Starting motor capacity	V-kW	12V 2.8kW
	Battery capacity	V-Ah	12V 80AH
	Fuel comsuption	g/kW.h	272

For more information about the diesel CHP, please consult with your sales representative.Thanks.
